| Memorandum for HPA |
| Power supply for Heater and Grids. | ||
|
||
| Voltage | 送信時 (ex.) TX (ex.) |
受信時 (理想) RX |
受信時 (現実1) RX ex.1 |
受信時 (現実2) RX ex.2 |
|||
| Plate |  ON (2000V) |
OFF |
ON |
ON |
|||
| Screen grid |
ON (300V) |
OFF |
ＯＮ （ＯＦＦが望ましい） |
GND |
|||
| Control grid |
ON (-55V) |
Zero |
Ｃut ＯＦＦ （送信時よりマイナス） |
ON (-55v) |
|||
| Heater | ON (6.3V) |
ON |
ON |
ON |
|||
| Drive | ON (10W) |
OFF |
OFF |
OFF |
|||
| Output | ON (500W) |
OFF |
OFF |
OFF |
 |
 |
 |
 |
